12HP~15HP 2WD Walking Tractor (Power Tiller)
tractor
12HP~15HP 2WD Walking Tractor (Power Tiller) Specifications
1,Walking tractor Compact structure, 2,Walking tractor Long lifespan 3, Easy to operate, 4,Sufficient power
Model
DF-12/15
Overall dimensions(L×W×H) (mm)
2680×960×1250
Wheel tread (mm)
800 740 640 580
Ground clearance (mm)
182
Tyres
6.00-12
Construction weight (kg)
360
Walking Speed (km/h)
Forward
1.4 2.5 4.1 5.3 9.4 15.3
Reverse
1.0 3.8
Rotary cultivator speed(rpm)
High 256 ; Low 188
Engine model
S195/S1100
S195NL/S1100NL
Type
Single cylinder,
horizontal, 4 stroke,
hopper water cooled
diesel
hopper water by diesel
condenser
Rated power[kW(hp)]
8.82 (12) 11.03(15)
Rated speed (rpm)
2000
Net weight(kg)
130
